Short Description:

At YMS, we specialize in the fabrication and assembly of flexible PCB products for use in the manufacturing of medical devices and various types of telecommunication and industrial equipment. Our custom PCB manufacturing capabilities allow us to develop and produce a top-performing flex PCB that meets your unique requirements. We can also work with you to produce a custom flex PCB prototype that will significantly improve your prospects of a successful project outcome. For detailed capabilities.

Parameters

Layers: 2
Base Material:Polyimide，1OZ，0.2MM finished
Minimum Line Width/Clearance：1.0mm/0.8mm
Size：35mm×20mm
Surface treatment：Lead Free Hasl

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Cost Effective Flex & Rigid-Flex PCBs

When it comes to our flex and rigid-flex products, we offer a variety of cost effective solutions and capabilities that include single or double sided circuitry to higher technology multilayer designs up to 20 layers. From selecting the best functional configuration, to choosing the proper connectors or components, we will help you meet or exceed all your applications requirements.

Our flex and rigid-flex PCBs are manufactured for various applications in the medical, military, aerospace, and portable devices industries.

Our engineering team can assist you from early design stages of your application all the way to end product production for all your flex and rigid-flex circuit needs.

Flex & Rigid-Flex PCB Manufacturing Lead Times

It's important to note that all lead times are technology dependent.

Flex：1-10 days (2-week standard lead)

Multilayer Flex (3-6 layers):2-15 days (3-week standard lead)

Multilayer flex (8-30 layers):7-20 days

Rigid-flex (2-6 layers):5-15 days (3-week standard lead)

Rigid-flex (8-30 layers):7-20 days

Feature	Capability
Quality Grade	Standard IPC 2
Number of Layers	1 - 8layers
Order Quantity	1pc - 10000+pcs
Build Time	2days - 5weeks
Material	DuPont PI, Domestic Shengyi PI
Board Size	Min 66mm, Max 406610mm
Board Thickness	0.1mm - 0.8mm
Copper Weight (Finished)	0.5oz - 2.0oz
Min Tracing/Spacing	3mil/3mil
Solder Mask Sides	As per the file
Solder Mask Color	Green, White, Blue, Black, Red, Yellow
Solder-stop coating---Soldermask oil	Green, White, Blue, Black, Red, Yellow
Solder-stop coating---Coverlay	PI and PET film
Silkscreen Sides	As per the file
Silkscreen Color	White, Black, Yellow
Surface Finish	HASL - Hot air solder leveling Lead - free HASL - RoHS ENIG - RoHS Immersion Tin - RoHS OSP - RoHS
Min Annular Ring	4mil
Min Drilling Hole Diameter	8mil
Min. hole size---Drilling (PTH)	0.2mil
Min. hole size---Punching (NPTH)	0.5mil
Tolerance of dimension	±0.05mm
Other Techniques	Peelable solder mask Gold fingers Stiffener (only for PI/FR4 substrate)
