HDI PCB 12 Layer 2 Step HDI Board | YMS PCB

Short Description:

HDI PCB is the short form of high-density interconnect printed circuit board, a kind of printed circuit board manufacturing technology.

An HDI PCB is a circuit board with a relatively high circuit density that uses micro-blind and buried “via”—or the copper-plated holes in PCBs—technology.

HDI PCB are compact products designed for small-capacity users, as they cost much more than standard PCB.

The birth of the HDI PCBs brings more possibilities for portable electronic devices and more challenges for PCB manufacturers.

For accommodating the trend of miniaturization and multifunction of electronics, YMS has done a lot to improve the level of equipment and staff professionalism.

You can be assured to offer us the HDI designs, and we will give you a satisfactory service and HDI products.


Product Detail

FAQ

Product Tags

Parameters

Layers: 12

Base Material:FR4 High Tg EM827

Thickness:1.2±0.1mm

Min.Hole Size:0.15mm

Minimum Line Width/Space:0.075mm/0.075mm

Minimum Clearance between Inner Layer PTH and Line: 0.2mm

Size:101mm×55mm

Aspect Ratio:8 : 1

Surface treatment:ENIG

Speciality: Laser via copper plated shut,VIPPO Technology,Blind Via and Buried Hole

Applications:Telecommunication

What is  HDI PCBs?

High density interconnect (HDI) PCBs represent one of the fastest-growing segments of the printed circuit board market. Because of its higher circuitry density, the HDI PCB design can incorporate finer lines and spaces, smaller vias and capture pads, and higher connection pad densities. A high-density PCB features blind and buried vias and often contains microvias that are .006 in diameter or even less.

1.Multi-step HDI enables the connection between any layers;

2.Cross-layer laser processing can enhance the quality level of multi-step HDI;

3.The combination of HDI and high-frequency materials, metal-based laminates, FPC and other special laminates and processes enable the needs of high density and high frequency, high heat conducting, or 3D assembly.

HDI PCB

YMS HDI PCB manufacturing capabilities:

YMS HDI PCB manufacturing capabilities overview
Feature capabilities
Layer Count 4-60L
Available HDI PCB Technology 1+N+1
2+N+2
3+N+3
4+N+4
5+N+5
Any layer
Thickness 0.3mm-6mm
Minimum line Width and Space 0.05mm/0.05mm(2mil/2mil)
BGA PITCH 0.35mm
Min laser Drilled Size 0.075mm(3nil)
Min mechanical Drilled Size 0.15mm(6mil)
Aspect Ratio for laser hole 0.9:1
Aspect Ratio for through hole 16:1
Surface Finish HASL, Lead free HASL,ENIG,Immersion Tin, OSP, Immersion Silver, Gold Finger, Electroplating Hard Gold, Selective OSP,ENEPIG.etc.
Via Fill Option The via is plated and filled with either conductive or non-conductive epoxy then capped and plated over
Copper filled, silver filled
Laser via copper plated shut
Registration ±4mil
Solder Mask Green, Red, Yellow, Blue, White, Black, Purple, Matte Black, Matte green.etc.

You May Like:

1、The application range and circuit advantage of HDI board are introduced

2、PCB production skills: HDI board CAM production method

3、PCB design of 1 step, 2 step and 3step HDI

4、HDI PCB Manufacturing Process

5、Where are HDI PCBs used

6. How are ceramic PCBs made

7. What is ceramic PCB?

8. What Is High Speed PCB

9. What is multilayer PCB

10. Double Sided PCB | Types of PCB





  • Previous:
  • Next:

  • What is HDI in PCB?

    HDI Boards – High Density Interconnect

    What are the layers of a PCB?

    Substrate Layer.

    Copper Layer.

    Soldermask layer.

    Silkscreen layer.

    What is HDI stackup?

    HDI is short for high density interconnect, and refers to the use of buried, blind and micro vias as well as any layer HDIs to create compact boards.
